Page
Introduction .............................................................................. 2
Mounting Preparation............................................................... 3
Mounting Information ............................................................... 4
Encoder Dimensions................................................................ 5
Backup Spar Dimensions ........................................................ 6
Mounting Requirements ........................................................... 7
Typical Mounting (s) ................................................................. 8
Encoder Installation Procedure ............................................... 9
Page
Spar Installation Procedure ..................................................... 11
Checking your Installation........................................................13
Electrical Shielding ................................................................ 14
Troubleshooting ..................................................................... 15
Mechanical Specifications ..................................................... 16
Output Signals and Pin-Outs ................................................. 17
Electrical Specifications ......................................................... 18
The ACU-RITE Warranty ....................................................... 19
• Installation brackets and kits are available.
• Your Authorized ACU-RITE Distributor can assist you with your
selection of these for your installation.
1 ACU-RITE
®
Motor mount
Reading Head
bracket
Horizontal mt.
bracket
Extension
bracket
Side mount
bracket
Rear mount
bracket
ENC150 Table of Contents
