ACV HeatMaster 71 - Table of Contents

EN
en
2
Table of ConTenTs
660Y1400 - A
GENERAL RECOMMENDATIONS ............................... 3
USER'S GUIDE .............................................................. 4
How to use this manual
....................................................................................4
APPLIANCE DESCRIPTION .........................................5
MCBA Interface
........................................................................................................5
CONNECTION DIAGRAMS AND ACCESSORIES ....... 6
High-temperature heating circuit controlled by a room
thermostat
..................................................................................................................6
Installation of two heating circuits controlled by room unit
and ZMC-2 module ............................................................................................ 10
Cascade installation.......................................................................................... 13
MCBA PARAMETERS FOR THE SPECIALIST ............ 14
Stand-by Mode (
) .............................................................................. 14
Parameter Mode ( ) ........................................................................... 16
info Mode ( ) ........................................................................................... 17
Code Mode ( ) .......................................................................................20
Setting the parameters ................................................................................ 21
Communication Mode (with code) : ................................................... 29
Fan Mode (with code) : ...................................................................................29
Error Mode (with code) : ................................................................................29
BLOCKAGE AND ERROR CODES .............................. 30
List of error codes + solutions [in error mode]
...........................30
