WaterMaster® 70-85
10
9
11
6
2
3
1
5
4
8
7
WaterMaster® 25-35-45
9
8
7
11
6
2
3
1
5
4
10
WaterMaster® 120
9
7
11
6
2
5
10
1
3
4
8
EN
FR
NL
ES
IT
DE
PL
RU
en
45
WaterMaster 25 - 35 - 45 - 70 - 85 - 120 : A1006482 - 664Y7300 • D
MAINTENANCE
Detail of the burner components
1. Gas connection
2. Gas valve
3. Air inlet elbow
4. Air inlet check valve
5. Venturi
6. Burner tube
7. Insulation
8. Burner hood
9. Burner hood insulation
10. Electrode
11. Fan assembly
