CUBE 2-360
7
polarity, the put the cover back.
2. Set the compensator locking grip 5 into ON position, two laser beams will be on.
If the switch is ON,that means the power is on and the compensator is working.
If the switch 5 is in intermediate position, that means the power is opened,the compensation is still locked, but it
will not warn if you issue the slope. It’s the hand-mode.
If the switch 5 is OFF, that means that the instrument is off, the compensator is also locked.
3. Press button 1 only once- horizontal beam will turn on. Press the button 1 one more time - vertical laser beam
will turn on. Again press the button 1 - horizontal and vertical beams will turn on.
4. Press button 2 once. Otdoor mode is activated. Press button 2 one more time. The instrument begins to work
in indoor mode.
