CUBE 2-360
8
To check the accuracy of line laser level
To check the accuracy of line laser level (slope of plane)
Set up the instrument between two walls, the distance is 5m.Turn on the Line Laser, and mark the
point of cross laser line on the wall. Rotate the instrument by 180° and mark the
point of cross laser line on the wall again.
Set up the instrument 0,5-0,7m away from the wall and make, as
described above, the same masrks. If the difference {a1-b2} and
{b1-b2} is less then the value of “accuracy” (see spesifications),
there is no need in calibration.
Example: when you check the accuracy of Cross Line Laser the
difference is {a1-a2}=5 mm and {b1-b2}=7 mm. The
instrument’s error: {b1-b2}-{a1-a2}=7-5=2 mm. Now you can
compare this error with standard error.
If the accuracy of Laser level isn’t corresponding with
claimed accuracy, contact the authorized service center.

ADA INSTRUMENTS CUBE 2-360 Specifications

General

Brand	ADA INSTRUMENTS
Model	CUBE 2-360
Category	Laser Level
Language	English
