4
S CONTROL MANUAL [ENGLISH]
To allow detailed editing of the User Presets in the S Series, hitting the ‚Open V‘ button
at the bottom right of the S Control window expands the editing interface [see previous
page]. This gives access to each of the six parametric EQs and the low and high shelving
filters in every preset, with separate software controls in the shelving filters for corner
frequency and gain [boost/cut]. The six parametric EQs each feature the same controls,
with the addition of a Q control in each EQ bank. Each parameter has its own on-screen
rotary control; settings can also be made by typing values straight into the displays
above each control.
In the middle of the application window are the buttons for loading and reading preset
information, with a pair of Read and Store buttons for each User Preset. Here the Read
button takes the current settings for the chosen preset from the corresponding loud-
speaker memory and displays them on the knobs and displays on the S Control inter-
face, while the Store buttons write the current settings shown in the app back to the
appropriate loudspeaker user memory.
The User Preset Save button on the left side of the S Control window allows user presets
displayed on the app to be saved to the connected computer via the standard Mac or PC
file-saving dialog boxes; the Load button next to it handles the reverse process whereby
presets stored on your computer can be loaded into the app, and from there back into
the speaker if required.
Should you require more detailed assistance with any aspect of S Series operation, the
Help button [to the right of the Action label] brings up buttons offering you access to
this user manual, and also contact details for ADAM Audio‘s Technical Support department
[see below]. A list of ADAM Audio’s representatives in your territory can be found at
www.adam-audio.com/en/find-a-dealer.
