Adax NEO H Series User Manual

program from submied list. If user is in edit mode on heater screen program's
values are displayed (look Menu connected/disconnected to WiFi).
Edit mode on
When heater is in direct mode (selected value is visible on the screen) click buon
„OK“ short.
When eding mode is acve on screen will be displayed that program from the list
which is set at the moment.
Direct mode
Heater is always working on direct mode. When heater is set to eding mode and
le for 30 s in standby it will automacally switch to direct mode and on screen last
set temperature's value will be displayed.
Wifi Control
When user is starng to use a mobile heang applicaon he can add acve heang
device to the applicaon by clicking both buons at the me „+“ and „-“unl on
the screen will be displayed „SC“ („SmartConfig“) and both indicaon lights turn
off. At that moment user can release buons. „SC“ will be displayed on the screen
unl configuraon is done. When it's done (that means applicaon found a
heater) on the screen red and green indicaon lights will turn on and blink. If
„SmartConfig“ can't find device an error message will be shown. Aer 30 s standby
heater is switching to the previous heang sengs (doesn't maer if
„SmartConfig“ was successful or not).
Note: user can try to register few heaters at once using „Smart heater“. To know
which heater is registering at the moment indicang red light on heater is showing
(read more at „Smart heater“ user guide).
Eding mode can't connect to WiFi
When new heater is not connected to the internet then it might not allow to use
weekly heang program because it can't locate present me. In this case eding
mode funcon list will look like this:
„HO“ - will be set 20°C temperature;
„AF“ - set heater to „Anfrost“ mode (by default 7°C);
„--“ - „stand-by“ mode.
Note: to choose a program user has to click buon „OK“. If user is not selecng a
program aer 30 s heater is switching to the direct mode and temperature is set to
the last one selected.
Eding mode connected to WiFi
Electric heang device connected to the home network and set to the eding
mode will display weekly heang programs which were configured using „Smart
heater“ applicaon.
If user have never used or haven't created any weekly heang programs then
these programs will be displayed:
„HO“ – weekly heang program „Home“;
„OF“ – weekly heang program „Office“;
„--“ – „stand-by“ mode;
„AF“ – will keep „Anfrost“ (by default 7°C).
Note: to choose a program user has to click buon „OK“. If user is not selecng a
program aer 30 s heater is switching to the direct mode and temperature is set to
the last one selected.
Temporary cancel all heang parameters
Temporary stop heater which is in direct mode use „+“ or „-“ to set needed
temperature.
Note: set temperature is working unl new weekly program heang mode will
start.
Factory data reset
To reset factory data on the electric heater (look. Heater screen) click buons at
once: “+”, “-” and “OK”, unl on the screen text starts blinking. Then release all
buons and 20°C temperature will be displayed. Aer factory reset electric heater
is keeping „Comfort“ mode temperature (by default 20°C ).
Note: aer factory reset heater must be registered at „Smart heater“ applicaon.
User will have to add „Smart heater“ applicaon and do „Smart Config“.
Thermostat layout
1 Display:
·Set temperature value. It is represented in integers and Celsius degrees.
2 Temperature indicaon light. Possible indicaons:
·Is lighng when heater is on set temperature;
·Is not lighng when heater's temperature is not reached;
·Blinking – when heater is connecng to the cloud.
3 WiFi indicaon light. Possible indicaons:
·Permanently lighng, when electronic heater device is connected to home net
(router) and cloud;
·Not lighng – when heater isn't connected to home network;
·Blinking – when heater is connected to home network but isn't connected to
cloud.
4 Funcons selecon and confirmaon buon „OK“. Used:
1. When heater is in direct mode:
By briefly clicking the buon system is switching from direct mode to eding
mode;
2. When heater is in eding mode:
·By briefly clicking the buon a weekly heang program is selected.
5 Buon „+“, possible values:
1. When heater is in direct mode and user is clicking it temperature values are
increasing by one degree. Possible temperature interval is 5-35°C. Max value
is „35°C“.
2. When heater is in eding mode and user is clicking this buon then program
list is displayed and user is navigang through it by going forward.
6 Buon „-“, possible values:
1. When heater is in direct mode and user is clicking it temperature values are
decreasing by one degree. Possible temperature interval is 5-35°C. Min value
is „5°C“.
2. When heater is in eding mode and user is clicking this buon then program
list is displayed and user is navigang through it by going backwards.
Display values
„20“ Integer temperature value. Interval 5-35°C.
„HO“ “Home” weekly program. By selecng it heang temperature will be:
1. If heater is not connected to home network it will keep 20°C. Unl user
using „+“ and „-“ won't change it;
2. If heater is connected to home network it will keep temperature by using
„Home“ program.
„OF“ “Office” weekly program. By selecng this mode, heang will be:
1. If heater is not connected to home network it won't be shown for user;
2. If heater is connected to home network, heater will keep “Office”, program
temperature.
„--„ The heater is in “stand-by” mode.
„AF“ Anfrost weekly heang program. By selecng it, heater will keep
,,Anfrost temperature (by default 7°C).
„SC“ „Smart config “indicang value, showing that user started adding heater,
to „Smart heater“ app (look,Heater's „Smart“ configuraon sengs).
„rE“ Factory reset indicaon value (look Factory data reset).
Introducon
This document aim is to introduce user with electric heater system and it's
funconality. Also possible usage ways and facilies.
This applicaon is inappropriate to use for adults and kids if they have the
following condions: physical or mental disabilies, lacking knowledge or
informaon about the product. Except those cases when they are being
supervised or they had introducon with tutorial how to use this applicaon.
Kids are not allowed to play with this device or le alone with it.
Turning heater on
Electric heater device can be turned on in two ways:
1. Briefly clicking on/off buon on the electronic heater device side;
2. Briefly clicking buon „OK“ on the electronic heang device screen.
Note: when heater is turned on for the first me on the screen 20°C temperature
will be shown. Heater is starng to work instantly.
Turning heater off
Heater can be turned off in three ways:
1. Clicking and holding buon „-“ (in direct mode) unl temperature on screen
will change into the text „--“ (temperature will start decreasing descending);
2. In eding mode choosing value „--“ in the menu list;
3. Clicking heater's on/off buon on the side;
Turning heater on aer turning it off manually heater is working by the heang
parameters set in last me.
Work modes
Electric heang device has two work modes:
1. Direct – direct control mode when on screen set heang temperature is visible;
2. Eding – eding mode. In this mode user can choose configured weekly
2017-06-12 art. no.: 62008
7

Adax NEO H Series Specifications

General

Type	Electric Panel Heater
Safety	Overheat Protection
IP Rating	IP24
Voltage	230V
Frequency	50/60 Hz
Material	Steel
Color Options	White, Black, Silver
Thermostat	Electronic
Installation	Wall Mounted
Features	child lock
Power Output	2000W
