www.adblighting.com Quick Start - page 2

Issue 1.0

Connecting your IMAGO to peripherals

Connect the power cable from the 12 V Power supply

Connect the computer to this USB port with the USB cable delivered with the

product

Connect any USB device in the USB ports

Connect the DMX 5 cable(s)

Connect the desk lamp

Computer Specifications

IBM compatible PC minimum system requirements:

 Dual Core Processor with 2.9 GHz CPU (recommended: Intel i3 or higher)

 2 GB RAM (recommended: 4 GB RAM)

 Hard-drive with minimum 64 GB (recommended type: SSD)

 Network card 100/1000 T/TX

 USB 2.0

 Graphics card

 Use High-end graphic cards with high-speed memory and a graphic processing

unit (GPU).

 Resolution: 1920 x 1080

 Operating systems:

1. Microsoft Windows 7

2. Microsoft Windows 8

Please run HATHOR software with all administrator rights.

Drivers Installation

The use of the IMAGO with your computer needs specific drivers.

The installation of IMAGO drivers is automatic. Start the computer, connect the IMAGO,

and install the version of HATHOR located on the USB device included in the HATHOR

software package.

Start the installation process of HATHOR via the installer (double click on the icon, and

follow the instructions).

During the installation, the drivers for IMAGO will be automatically installed.

Note: PREGO users can use any available version PREGO from 1.7.0.0.
