Table 5. Capacities with Full Solar Load, 239 T1 Repeaters
Vendor Description Model No.
HDU-409
Doubler
Capacity
239 T1
Repeater
Capacity
Recommended
Slot
Assignment for
Maximum
Capacity
AT&T Outdoor dual
chamber
pole/wall
mount
819 14 25 1, 3, 5, 7, 8, 10,
12, 14, 15, 17,
19, 21, 23, 25
(See Figure 4)
Outdoor 841
cabinet
27A, B, C or D
shelf
13 per
shelf/
52 total
25 per
shelf/
100 total
All odd slots
Outdoor
cabinet
809 6 12
(a)
ALCATEL
(Available
from
Charles
Ind.)
Outdoor
canister,
pole/wall
mount
621204 6 12
(a)
621205 11 25 All even or odd
slots from 1 to
12, plus 14,17,
19, 22 and 25
621206 19 50 All even or odd
slots from 1 to
12, plus 14,17,
19, 22, 25, 28,
31, 34, 35, 38,
41, 44, 48
CHARLES Outdoor
canister,
pole/wall
mount
CIAC4306 3 6
(a)
CIAC3300 2 3 1, 3
CIAC5312 5 12
(a)
CIAC5325 7 25 1, 3, 5, 7, 9, 11,
13, 15, 17, 22
24
CIAC5350 9 50 All odd slots
from 1-33
CIAC6321 2 2 All slots
SIERRA
SUNRISE
Outdoor
canister,
pole/wall
mount
3011 3 6
(a)
3021 3 5 1, 3, 5
