ADC AD-333 Installation Manual

6 American Dryer Corp. 112175-9
MAXIMUM CAPACITY (DRY WEIGHT) PER POCKET 30 lb
13.60 kg
TUMBLER DIAMETER 27-1/4”
69.21 cm
TUMBLER DEPTH 30”
76.20 cm
TUMBLER VOLUME
PER POCKET 10.1 cu ft
286 L
TUMBLER/DRIVE MOTOR
PER POCKET 1/2 hp
0.37 kW
BLOWER/FAN MOTOR
PER POCKET N / A
DOOR OPENING
(DIAMETER) 21-1/2”
54.61 cm
DOOR SILL HEIGHT
TOP POCKET / BOTTOM POCKET 52-7/8” / 14-1/4”
134.3 cm / 36.2 cm
WATER CONNECTION N / A
DRYERS PER 20’/40’ CONTAINER 11 / 22
DRYERS PER 48’/53’ TRUCK 30 / 33
VOLTAGE AVAILABLE 120-240V 1,3ø 2,3w 50/60 Hz
APPROXIMATE NET WEIGHT 675 lb
306 kg
APPROXIMATE SHIPPING WEIGHT 710 lb
322 kg
AIRFLOW
PER POCKET
60 Hz
400 cfm
11.3 cmm
50 Hz
340 cfm
9.6 cmm
HEAT INPUT
PER POCKET 72,000 Btu/hr
18,143 kcal/hr
EXHAUST CONNECTION
(DIAMETER) 8”
20.3 cm
COMPRESSED AIR CONNECTION N / A
COMPRESSED AIR VOLUME N / A
INLET PIPE CONNECTION
PER POCKET 1/2” F.N.P.T.
Specifications _____________________________________________________________________
NOTE: The manufacturer reserves the right to make changes in specifications at any time without notice or obligation.
GAS
Shaded areas are stated in metric equivalents 7/12/12
