ADC Fiber Optic Panel FL2000 Series - Termination Panels with Adapters;Pigtails; Panel Specifications

10/07 • 103743AE
Fiber Optic Panels
43
www.adc.com • +1-952-938-8080 • 1-800-366-3891
Rack Mount Panel Solutions
FL2000 Series Fiber Optic Panel
Fiber Termination Panels with Adapters or Pigtails
1
2
4
7
9
12-position 1.75" (1 RU)
24-position 3.5" (2 RU)
48-position 5.25" (3 RU)
72-position 8.75" (5 RU)
96-position 10.5" (6 RU)
Panel Capacity Panel Height
1
LC connectors and adapters double the capacity
of the panel by terminating two fibers at
each adapter.
2
6-fiber softwall bundle except with LC connectors,
which uses 12-fiber.
3
Mounting kit shipped unattached, if other than
standard mounting style.
FL2 -
Catalog Number
000-
0
5
Latch
K1 lock
Latch Type
Number
of Ports
Loaded
A
C
D
19" standard
19" flush mount
23" centered
Mounting Style
3
0
SC
LC
1
SC ultra polish
SC angled polish
FC ultra polish
LC ultra polish
1
LC angled polish
1
Multimode
9
6
Singlemode
7
J
2
8
B
Connector and Adapter Type
R
A
P
R
C
Adapter-only
Singlemode or multimode 62.5/125 µm
stranded softwall bundle
Singlemode or multimode 62.5/125 µm
12-fiber ribbon
Multimode 50/125 µm
stranded softwall bundle
Pigtail or Adapter Type
2
126 mm
(5")
257 mm
(10.1")
498 mm
(19.6")
133 mm
(5.25")
Other configurations are available upon request. Please contact ADC Technical Assistance Center.
Features
• Termination-only panel
• VCG ships with each panel
• Uses FL2000 6paks with angled retainers
72-Position Termination Panel
48-Position Termination Panel
