Recommended
calibration period
One year
Update rate
10/Sec、3/Sec (default)、1/Sec、1/15Sec
Operating temperature
-10℃~50℃ Guaranteed accuracy
Performance
Overload pressure
1.2X
Battery
2 x AA alkaline (LR6) batteries
Recommend: Duracell MX1500 、EnergizerE91、Panasonic LR6、GP 15AU
Power Supply
Battery life
10/Sec:1,500 Hours、3/Sec:3,000 Hours、1/Sec:6,000 Hours、1/15Sec:12,000 Hours
Wetting parts
Wetted surface: All wetted surfaces are 316L stainless steel with welded design for
gauges ≤10,000 psi (no O-ring, thread tape, epoxy, or sealant on any part of the sensor
assembly), and copper O-ring design for gauges > 10,000 psi.
Case PC+ABS
Material
Protecting cover
Silicone Rubber
3.0 VDC Imax=30 mA Pmax =90 mW
Rated Power
Rated
16
