18
Dimensions
Φ100 mm x 40 mm, total height: 157 mm (4" x 1.6" x 6.2")
Weight
500 g (1.1 lbs)
Fitting
1/4 NPT, 1/2 NPT, 1/4BSP, M20×1.5, autoclave (male or female)or custom-made
Others
Auto off
Disabled、15、30、45、60、90、120 minutes , user selectable.
Filtering
Averaging (3 to 10 samples) or low-pass first-order filter.
Additional functions
Engineering units
Backlight duration
Disable auto off,15,30,45,60 seconds , user selectable
Max/Min data capture
Capture the Max and Min data during pressure measurement
Key lockout
To avoid mis-operations. When the gauge is in auto-storing status,
buttons will be locked automatically.
Overpressure alarm
Display will flash over 120%FS
Battery voltage
measurement
Extend units:
2 2
Pa, kPa, mPa, bar, mbar, psi, kgf/cm , mmH₂O, mmHg, inH₂O, inHg, ozf/in , %, ℃, ℉
inH₂O(20℃), inH₂O(60℉), mmH₂O(20℃), mmH₂O(15℃), ftH₂O(60℉), ftH₂O(4℃)
gauge will be power-off automatically.
To measure and display the battery voltage. When the battery voltage is too low,
This allows users to set a multiplier factor to be multiplied by the kPa measured pressure.
For example: 2 kPa=0.02 bar (2*0.01)，factor：0.01，a 2 kPa pressure will display as 0.02.
(ADT680 can be set by the factory or via the Land/Wireless software) )
