Addvent AVX100WLED - Product Features and Kit Contents; Site Preparation and Installer Requirements

This appliance can be
used by children aged
from 8 years and above
and persons with reduced
physical, sensory capabilities
or lack of experience and
knowledge, if they have
been given supervision or
instruction concerning the
use of the appliance in a
safe way and understand
the hazards involved.
Children shall not play with
the appliance. Cleaning and
maintenance of the appliance
shall not be made by children.
The Addvent AVX100WLED has
thefollowingfeatures:
• Singlespeedextraction
• 12V(ac)fanoperation
• 12V(dc)lightoperation
• Whenswitchedo,thefancontinuestorunfora
pre-setdelayfrom30secondsto30minutes.
• AtransformerprovidesaSafetyExtraLow
Voltage(SELV)powersupply.
• THEAPPLIANCEISDOUBLEINSULATED
ANDDOESNOTREQUIREANEARTH
CONNECTION.
Thecontentsofthiskitincludes:
• Whisper Silent Showerlight and Fan
• 1xSafetyExtraLowVoltage(SELV)
Transformer
• 1x3mflexibleduct
• 1xExternalWallGrill
• 2xTiewraps
• 7xScrewsandwallplugs
Where to locate the unit
• Locateintheceilingabovethe
showerareaorcubicle.
• Atleast110mmfromtheedgesof
themountingsurfacetothecentre
ofthehole.
• Notwhereambienttemperaturesarelikelyto
exceed50°C.
• Ifinstallinginaroomcontainingafuelburning
devicewhichhasanon-balancedue,itisthe
installer’sresponsibilitytoensurethatthereis
enoughreplacementairtopreventfumesbeing
drawndowntheuewhenthefanisoperating
uptomaximumextract.RefertoBuilding
Regulationsforspecicrequirements.
• Exhaustairmustnotbedischargedintoaue
usedforexhaustingoffumesfromappliances
suppliedwithenergyotherthanelectric.
Requirementsofallauthoritiesconcerned
mustbeobservedforexhaustairdischarge
andintakeowrates.
• Notsuitableforuseinpossiblechemical
corrosiveatmospheres.
What the installer will need
• 3mmelectrician’sscrewdriverand
No.1or2Pozi-drivescrewdriver.
Beforeyoustart,youwillalsoneed
• A100mmdiameterpreparedholefortheunit.
• A100mmdiameterpreparedholeforthe
externalvent.Ideallypositionedtoallow
condensationtorunawayfromtherstbend
intheducttowardtheexternalvent.Referto
Figure5.
• Aplannedroutefortheduct,pleaseconsider
thefollowing:
- Theductis3minlength.
- Thefanwillperformbestifductingiskept
asstraightandasshortaspossible.Avoid
sharpcorners.
- Fromthebackofunittheductshould
protrudestraightoutforatleast60mmbefore
therstbend.Thisistoensurethatthe
backdraftapsarefreetoopenandclose.
- Layingtheductsothataftertherstbend
thecondensationrunsouttowardsthe
externalvent.RefertoFigure5.
• Somesuitableinsulationfortheduct,ifthe
ductpassesthroughacoldorunheated
space.Alternativelyyoucanuseaninsulated
duct.
• Ameansfordisconnectionofallpoles
(Isolatingswitch).Thismustbeincorporated
intothefixedwiringinaccordancewiththe
wiringregulations.Ifmetalswitchboxesare
used,earthingregulationsmustbefollowed.
• Asuitableoperatingswitch.
• Twolengthsofsuitablyrated2corecablefor
wiringfromtransformertotheunit.
• Suitablyrated3corecableforwiringfromthe
mainssupplytothetransformer,viatheisolating
switchandoperatingswitch,asnecessary.
