Before starting operations in this section:
1) Find a place where there is power supply nearby.
2) As shown in Fig.5 and Fig.5a, install the exhaust hose, and adjust the
window position well.
3) As shown in Fig. 6, connect drain hose well (only for using heating model) ;
4) Insert the power cord into an grounded AC220~240V/50Hz socket;
5) Press the POWER button to turn on the air-conditioner.
1. Before using
Notice:
- Operation temperature range:
Maximum cooling Minimum cooling
DB/WB(ºC) 35/24 18/12
Maximum heating Minimum heating
DB/WB(ºC) 27/--- 7/---
Check up whether the exhaust hose has been mounted properly.
Cautions for cooling and dehumidifying operations:
- When using functions on cooling and dehumidifying, keep an
interval of at least 3 minutes between each ON/OFF.
- Power supply meets the requirements.
- The socket is for AC use.
- Do not share one socket with other appliances.
- Power supply is AC220--240V, 50Hz
2. Cooling operation
- Press the “Mode” button till the “Cool” icon appears.
- Press the “ DOWN ”or“ UP ”button to select a desired room
temperature. (16ºC-31ºC)
- Press the “ WIND ” button to select wind speed.
3. Dehumidifying operation
Press the “Mode” button till the “Dehumidify” icon appears .
- Automatically set the selected temperature to current room
temperature minus 2ºC. (16ºC-31ºC)
- Automatically set the fan motor to LOW wind speed.
4. Fan operation
- Press the “Mode” button till the “Fan” icon appears.
- Press the “ WIND ” button to select wind speed.
5. Heating operation (this function is not available for a cold-single unit)
- Press the “Mode” button till the “Heat” icon appears.
- Press the “ DOWN ”or“ UP ” button to select a desired room
temperature. (16ºC-31ºC)
- Press the “ WIND ” button to select wind speed.
Fig. 6
Fig. 5 & 5a
