5.1 Installation and connection
S/N Description S/N Description
1 Fan net 11 Warming plate
2 Fix screw 12 Chain case
3 Driven shaft bushing 13 Driving wheel
4 Pizza pan plate 14 Driving shaft& bushing
5 Driven wheel 15 Fix screw
6 Fix holder 16 Oil collector
7 Mesh net 17 Controlling panel
8 Fix case for mesh net 18 Connecting board
9 Housing 19 Oven holder
10 Fix screw of warming plate 20 Castor
This holder is optional. Clients can buy this additionally, based on his own
needs.
5.2 Safety instructions
WARNING! Electrical hazard!
The appliance should be connected to a suitable power receptacle. The outside body should
be earthed properly. Never yank or pull the power cord violently to disconnect from outlet.
Touch of power cord with any hot parts is absolutely forbidden.
