ADF LINEA 820 NMV ZERO CLEARANCE BOX ASSEMBLY INSTRUCTIONS 1/8/23
8
Zero Clearance Box Assembly:
ZERO CLEARANCE BOX Parts Materials list - Check all parts supplied before beginning
assembly.
Stand Base assembly parts, 4 Shorter
Uprights, 4 Side bearers with Tabs and 4
Long Rails, Hardware kit for Assy.
1 x Base Panel with 6 ob-round air slots
1 x Top panel with Flue hole
Pictured below Left to Right: 2 x Support
Rails, 2 x Flue stand off spacers, 1 x Rear
spacer and 1 x Deflector for Centre air slots
1 x Back panel
2 x Side panels front air
