Adidas R-21 User Manual

15 R-21 WATER ROWER
WWW.ADIDASHARDWARE.COM 16
PARTS LIST
NO. PART DESCRIPTION QTY
1 Console 1
2 Screw M8*P1.25*20L 4
3 Bushing φ38.1 Black 2
4 Upper connected wire 1
5 Lower connected wire 1
6 Upright 1
7 Frame 1
8 C2 Roller 6
9 Screw M10*90L 1
10 Nylon nut M10 1
11 Elastic rope 1
12 Roller 2
13 Batteries box holder 1
14 Screw M5*12L 8
15 Batteries box cover 1
16 Screw ST3.9*12L 1
17 Control board B801-D 1
18 Screw M6*12L 8
19 Fixing plate 1
20 Screw M8*P1.25*16L 4
21 Block (Black) 4
22 Fixing plate 1
23 Screw M8*P1.25*60L 2
24 Nylon nut M8*7T 9
25 Screw M8*P1.25*80L 1
26 C2 Bushing 12
27 Bearing 6000 2ZZ 6
28 Roller 3
29 U shape holder 1
30 Screw M8*P1.25*55L 1
31 Screw M6*P1.0*35L 3
32 C2 inner bushing Ø6*Ø8*20L 3
33 Flat washer Ø6.5*Ø13*1T 5
34 Nylon nut M6*5.5T 3
35 Water tank holder 1
36 Pull rope 1
NO. PART DESCRIPTION QTY
37 Handlebar 1
38 Screw M5*10L 18
39 Lower pedal cover 2
40 Pedal adjust pad 2
41 Pedal strap 750*25*1T 2
42 Pedal fixing plate 2
43 EVA pad 2
44 End cap 4
45 End cap 1
46 Lower cover of water tank 1
47 Washer 1
48 Upper cover of water tank 1
49 Block 1
50 Screw M4*143 12
51 Flat washer φ4.5*φ11*1.5T 12
52 Nylon nut M4 12
53 O-Washer φ9*φ5*φ2 2
54 Screw M6*20L 8
55 CH20 Plate 1
56 Bolt φ6*60 2
57 Shaft 1
58 Wave washer Ø20.5*Ø30*0.3T 1
59 U80 Bushing 2
60 Pull wheel 1
61 Strong magnet Ø15*4 3
62 Spring 1
63 Screw M5*10L 1
64 Plate 1
65 Locked block 1
66 P106 Insert S41*9.35L 1
67 One way ratchet HF2016 1
68 Bearing 6804 2RS 2
69 Screw M6*16L 2
70 Reinforced plate 1
71 Screw M6*12 6
72 Lower bearing housing 1
NO. PART DESCRIPTION QTY
73 CH2O Upper bearing housing 1
74 Bearing 6004 2RS 2
75 C-shape clasp Ø18.5*Ø22.5*1T 2
76 P106 Sensor bracket 1
77 Lower sensor of wire 2
78 Screw M5*10L 1
79 CH2O Plate φ100*2T 1
80 CH2O Bearing house 1
81 P106 gasket φ90*φ50*5.3T 1
82 TC φ32*φ22*7 1
83 Semicircle cover 1
84 Screw M5*16L 6
85 Screw M8*P1.25*50L 2
86 Flat washer Ø8.5*Ø16*2T 19
87 Front stabilizer 1
88 Front Stabilizer end cap (L) 1
89 Screw ST4.8*12L 8
90 Screw ST3.9*50L 4
91 Inner cover 2
92 Front Stabilizer end cap (R) 1
93 Block 1
94 Front holder 1
95 Cover sheath 1
96 Round cover 2
97 Upper cover 1
98 Lower cover 1
99 Screw ST3.5*16L 4
100 Screw 3/16"*3/4" 4
101 Handlebar bracket 1
102 Fixing plate 1
103 Seat 1
104 Slider cover 2
105 Flat washer Ø6.5*Ø16*2T 4
106 Slider 1
107 Screw M8*30L 6
108 C2 Roller bushing Ø16*Ø8.2*18.8L 6
NO. PART DESCRIPTION QTY
109 Lower Roller 2
110 Flat washer Ø8*Ø14*1T 6
111 Upper Roller 4
112 Screw M8*P1.25*16L 10
113 P500 Rail 100*54*1300L 1
114
Support tube
40*80*2T*1296L(90°,45°)pipe
1
115 Light -strips 1
116 Upper sensor wires 2
117 Lights cover 1
118 Screw M5*16L 7
119 Buffering pad 4
120 Nut M6 4
121 Screw M6*75L 4
122 End cap for rail 1
123 Lower supporting base cover 1
124 Rear stabilizer 1
125 Upper supporting base cover 1
126 Rear stabilizer end cap 2
127 CH2OWater absorption 1
128 Harpoon wrench 13.14.15 1
129
Hexagon wrench
6mm*30mml*84mml
1
130 Screw M6*20L 2
131 Generator 1
132 Battery connection wire 1
133 Belt 1
134 Screw M8*P1.25*20L 1
135 C-shape clasp Ø12 2
136 Driving wheel 1
137 Nylon nut M10 5
138 Screw M6*16L 4
139 Lighting PCB 1
140 Screw M5*12L 8
141 Bearing 6901ZZ 2
142 Bushing Ø12*Ø8.5*65T 2
143 Spring washer Ø8.1*2.5T 11
NO. PART DESCRIPTION QTY
144 AA Batteries 7
145 Middle lights connected wire 2
146 Upper lights connected wire 1
