This document provides assembly instructions and details for the ADIRoffice Two Tier Chair Cart, Model No. 690-03.

Function Description

The ADIRoffice Two Tier Chair Cart is designed for securely storing and transporting up to 84 folding chairs. It features a two-tier design and is equipped with swivel caster wheels for easy mobility. The cart is constructed from strong, powder-coated steel tubing, ensuring durability and secure service for organizations.

Important Technical Specifications

Folding Chair Capacity: 84 chairs
Total Weight Capacity: 1,000 lbs.
Color: Black
Finish: Powder Coated
Dimensions:
- Length: 64.8 inches (166 cm)
- Width: 33 inches (86 cm)
- Height: 67.1 inches (170 cm)

Usage Features

The cart is designed for indoor use and efficient storage of folding chairs.

Mobility: Equipped with swivel caster wheels, including two locking caster wheels, for easy movement and secure positioning.
Two-Tier Design: Allows for organized storage of a large number of chairs.
Chair Hangers: Six chair hangers are provided to neatly hold chairs.
Security: Bungee cords are provided to secure tables on the cart, although the primary function is for chairs.
Safety Guidelines:
- Not to be used or stored outdoors as it is not weather-proof.
- Not designed for standing or riding on, as it can be dangerous.
- Should only be used for folding tables and chairs to prevent tipping.
- Caster wheels must always be locked when the cart is stowed full.
- Do not exceed the recommended number of chairs and tables.
- Always secure tables with the provided bungee cords.
- Requires two people to load and unload for safety.

Maintenance Features

Regular maintenance helps ensure the longevity and safe operation of the chair cart.

Cleaning: Dampen a cloth with water and clean the cart as needed. Avoid using chemicals or cleaning agents.
Bungee Cords: Inspect bungee cords for cracks periodically and replace them if necessary to ensure items remain secure.
Caster Wheels: Occasionally check the caster wheels for wear and tear. Replace and oil them as needed to maintain smooth mobility.

Parts List for Assembly

The package should contain the following components:

1 - Upper Rail
1 - Lower Rail
2 - Upright
1 - Mid Rail
2 - Base Rail
6 - Chair Hanger
2 - Caster Wheel
2 - Locking Caster Wheel
24 - Long Screw (M8 x 50)
12 - Medium Screw (M8 x 25)
4 - Small Screw (M8 x 20)
24 - Nut (M6)
16 - Nut (M8)
2 - Brace

Limited Warranty

ADIRoffice provides a limited warranty for this product:

Burglary Damage: Warrants against damage caused by attempted burglary for five (5) years from the date of purchase.
Defects: Warrants against defects in workmanship and materials for one (1) year from the date of purchase.
Non-Transferable: Warranties are not assignable or transferable.
Voiding Warranty: Misuse, tampering, abuse, neglect, accident, improper installation, modification, unauthorized service, destruction, alteration of the serial number, or violation of instructions will void the warranty.
Remedy: The sole responsibility of the Company is limited to repair or replacement of non-conforming components at no cost to the purchaser during the warranty period.
Service: Contact the Company directly for service. A Return Authorization Number is required for defective product returns. Proof of purchase, police/fire report, photographs of damage, and a written testimonial are required.
Shipping: The Company is not responsible for shipping losses or damages. Return authorized products must include a copy of the original invoice.
Not Insurance: This warranty is not an insurance policy and does not cover damage to or theft of the safe or its contents.
Validation: Complete and return the enclosed warranty card within ten (10) days of purchase to validate the warranty.

Disclaimer

ADIRoffice products are designed as a deterrent against theft, vandalism, burglary, or acts of God, but do not guarantee absolute prevention. The Company strives to offer the best products for crime prevention. By purchasing, users agree that products and information are provided "AS IS" with all faults. ADIRoffice disclaims all warranties, express or implied, including merchantability, fitness for a particular purpose, accuracy, or completeness. The entire risk of use lies with the user. In no event shall ADIRoffice or its suppliers be liable for consequential, incidental, special, indirect, or exemplary damages arising from the use or inability to use the products or information, including lost profits, business interruption, personal injury, loss of privacy, negligence, or costs of substitute goods. These limitations apply even if ADIRoffice has been advised of the possibility of such damages and notwithstanding any failure of essential purpose of any limited remedy. The total liability of ADIRoffice and its suppliers shall be limited to the greater of the amount actually paid for the products and information or U.S. $1. If any provision of this agreement is invalid, the remaining provisions remain in effect. ADIRoffice reserves the right to modify these terms and conditions at any time.

ADIROffice 690-03 - Parts Diagram
