ADJ Products, LLC - www.adj.com - Focus Spot Two Instruction Manual Page 6 ADJ Products, LLC - www.adj.com - Focus Spot Two Instruction Manual Page 7
Screw one clamp via a M12 screw and nut to the included
bracket. Attach the bracket using the omega locks to the
bottom of the Focus Spot Two. Attach and pull the safety-cable
through one of the safety holes located on the bottom base and
over the trussing system or a safe xation spot. Insert the end
in the carabine and tighten the safety screw.
NOTICE: The suitable enviromental temperature for this light-
ing xture is between -25˚ C to 45˚ C. Do not place this lighting
xture in an enviroment where the temperatures are under or
above the temperatures stated above. This will allow the xture
to run at its best and help prolong the xture life.
Focus Spot Two Mounting Focus Spot Two CAD Drawing
237mm/9.33”
385mm/15.15”
173mm/6.81”
Clamp
Suspender
Screew
