frequency response 40Hz to 22kHz, ±3dB
sensitivity 91.5dB with 2.83 volt RMS pink noise measured at 1
meter
impedance 4 Ohms, nominal
recommended power 20 to 150 watts RMS
tweeter 1" / 25mm diameter driver with a copolymer dome, a
single layer, oxygen-free copper voice coil wound on a
high-temperature Kapton form, and a precision- ground
neodymium magnet structure.
woofer 6-
1
/2" / 165mm driver with a curvilinear profile cone
made from an injection-molded copolymer filled with an
acid metasilicate of magnesium. The woofer features a
butyl-rubber surround and a 1” oxygen-free copper wire
voice coil wound on a high temperature Kapton form.
crossover Passive hybrid LCR network with precision, low DC
resistance, high current air-core coils and low-loss, close
tolerance, high Q, polypropylene capacitors. Thre e
position tweeter level switch and tweeter polarity
switch.
10
specifications
