ADS Active 40 - Back Panel Connections

CONTROLS & CONNECTIONS
4. Power On/Off
11. Mains Input Socket 240V
9. Right Output Speaker Connection
8. Right Input Balanced Connector
8. Left Input Balanced Connector
3. Bass Control
7.
3.5mm Stereo Input Jack Socket
1. Master Volume Control
13. Power Indicator
5. Left and Right Clipping LED Indicators
6. RCA Phono Input Connectors
2
.
Treble Control
10. Stereo/Parallel Mode Button
12. Heat Sink
