ADS Active 40 - Specifications and Installation; Technical Specifications; Fitting Instructions

Fitting Instructions
1. Use the Active 40 bracket as a template to mark the surface where the speaker
will be mounted.
2. The Loudspeaker can be mounted horizontally or vertically.
3. Mark and drill in the positions shown, PLEASE NOTE:
It is the responsibility of the installation engineer to position the
speaker in a safe place and to use the correct size screws &
rawlplugs (if required) to mount the Active 40 speakers safely.
Model
RMS
Input Sensitivity
Frequency Response
AC Power Supply
Treble Control
Bass Control
Dimensions
Weight
ADS Active 40
20W x 2 @8Ohm
0.5V
80Hz~18kHz/1W+/-0.5dB
220V~240V/50Hz~60Hz
+/- 10dB
+/- 10dB
183 X 200 X 240mm
4.7Kg
Specifications
