8) ASI Remux State: This quick view displays the status of ASI Remux status if the
feature is enabled.
9) *Modulator State: This quick view displays the status of RF Tx status if the unit is
equipped with optional modulator.
Transport LED Indicators - Channel 1 & 2
On - Video is detected on the selected input.
Blink - No video is detected.
Off - Device is not encoding. Idle State
On - Device is encoding.
Off - MPEG 2 module installed.
On - MPEG 4 (H.264) module installed.
Off - Encoding standard definition.
On - Encoding high definition.
Audio Encode Indicators - Channel 1 & 2
Off - Audio encoder configuration is set to off.
On - Audio encoder configuration is set to encode or passthru.
Blink - Audio pair is enabled but there is no payload on the input
