Adtec EN-30 - Menu System Navigation; Services Menu Configuration

Front Panel Menu Structure
Services Menu
The following diagram illustrates the structure and flow of the Services Menu on the Adtec
EN-30 device. TX MUX Rate, Table, and TSID are global configurations, while items under
the denoted << >> parallel menu are unique to each encoder :
Control
Function
Options
API
Command
TS MUX
Rate
Configures the total transport multiplex
rate. *Controlled by modulator when set
to Enable
1 - 150 Mb/s
*.ECMD0 TMR
Video
Autofill
Video Autofill automatically adjust the
Video Bit Rate to occupy the maximum
fill of the TS Mux Rate
ON
OFF
*.ECMD0 VAF
Tables
Configures the table generation standard
to be used.
DVB
ATSC
MPEG
DVB SDT Only
ATSC Cable
ATSC Terrestrial
*.ECMD0 TON
TSID
Transport Stream ID is a user-defined
value in the PAT packet used to identify
individual transport streams
0x0000 - 0xFFFF
*.ECMD0 TSI
ASI Mode
Configures the encoder to egress a
constant transport stream when video is
not present. It is recommended to keep
ASI Mode set to Continuous
ON
OFF
*.ECMD0 ASM
ASI
Remux
Reserves the bandwidth needed for
incoming ASI transport stream
Note: Setting value to zero disables ASI
Remux
0-100
Mb/s
*.ECMD0 TRS
ASI 0
Active
Configure each encoding module to be
turned on or off
ON
OFF
*.ECMD# STU
Service
Name
Name of the program or event, carried in
the SDT table of a transport stream
text field;
20-character
limit (incl.
spaces)
*.ECMD# SNA
Service
Provider
Name of the party offering the program
or event, carried in the SDT table of a
transport stream
text field;
20-character
limit (incl.
spaces)
*.ECMD# SPR
