RF Tx Menu
The following diagram illustrates the structure and flow of the RF Tx Menu on the Adtec
EN-30 device. This menu will not be available on units without the optional RF modulators.
Item
Function
Options
Transmit
Allows the operator to enable or
disable the Main RF output. If
Transmit is enabled and any value for
Type, Frequency, Rolloff, Symbol
Rate, or Interface Rate is changed,
then Transmit will be automatically
disabled. However, the monitor
output will remain active.
Disable
Enable
2.2
Type
Allows the selection of the mod type.
DVBS
DVB-S2
DVB-S2X
2.3
Mode
This control allows the operator to
select the desired modulation mode
and FEC code rate.
We display all possible ranges
available via our device in the
Front Panel. This list will differ
from the list found in the web UI
as it only shows those options
available based on the feature
keys found.
QPSK-1/2
QPSK-2/3
QPSK-3/4
QPSK-5/6
QPSK-6/7
QPSK-7/8
QPSK-1/4
QPSK-1/3
QPSK-2/5
QPSK-3/5
QPSK-4/5
QPSK-8/9
QPSK-9/10
QPSK-13/45
QPSK-9/20
QPSK-11/20
QPSK-11/45
QPSK-4/15
QPSK-14/45
QPSK-7/15
QPSK-8/15
QPSK-32/45
8APSK-5/9-L
8APSK-26/45-L
8PSK-3/5
8PSK-2/3
8PSK-3/4
16APSK-5/6
16APSK-8/9
16APSK-9/10
16APSK-7/15
16APSK-8/15
16APSK-32/45
16APSK-1/2-L
16APSK-8/15-L
16APSK-5/9-L
16APSK-26/45
16APSK-3/5
16APSK-3/5-L
16APSK-28/45
16APSK-23/36
16APSK-2/3-L
16APSK-25/36
16APSK-13/18
16APSK-7/9
16APSK-77/90
32APSK-3/4
32APSK-4/5
32APSK-5/6
32APSK-8/9
32APSK-9/10
32APSK-2/3-L
32APSK-32/45
32APSK-11/15
