Adtec EN-30 - IP Transmission Settings; IP Tx Menu Configuration

IP Tx Menu
The following diagram represents the structure of the IP Tx Menu Menu:
Control
Function
Options
API Command
Mode
switches multicast function on
and off
Off
Send
*.ECMD0 MMO
#
Tx IP Address
The IP Address of which the
Multicast or Unicast is broadcast.
Multicast addressing supports the
transmission of a single IP
datagram to multiple receivers.
Valid Multicast addressing range
is 224.10.XXX.XXX to
239.XXX.XXX.XXX. Unicast
addressing sends a single IP
datagram to only one receiver.
The Unicast address will be the
unique IP of the receiving device.
user-defined;
numeric field in
format
xxx.xxx.xxx.xx
x
*.ECMD0 MSI #
Tx Port
port assignment used for
transmitting a multicast
user-defined;
numeric field
*.ECMD0 MSP #
DVB per IP
Configures the amount of DVB
transport stream packets ( 188
bytes per DVB packet ) per IP
packet payload.
1
4
7
*.ECMD0 MSY #
RTP
Allows for sequence numbering
and timing for accurate playback.
On
Off
*.ECMD0 RTP #
FEC Mode
Forward Error Correction; selects
on/off. When selected, sends two
FEC RTP streams in addition to a
source RTP stream enabling a
receiver to reconstruct missing
packets in the source stream.
The RTP Control (above) must be
set to 'on' to enable FEC.
On
Off
Available if RTP
selected 'on'
*.ECMD0 FEP #
FEC L
affects the maximum burst packet
loss that can be recovered
4-20
*.ECMD FEP #
FEC D
defines latency involved in burst
recovery
4-20
*.ECMD FEP #
TOS
Type of Service helps define how
Normal
*.ECMD0 TOS #
