Adtec EN-30 - Conditional Access (CAS); CAS Menu Encryption Settings

CAS Menu
The following diagram illustrates the structure and flow of the CAS Menu on the Adtec
EN-30 device:
Control
Function
Options
API Command
Channel 1
Turns Service 1
Encryption ON/OFF
ON
OFF
*.ECMD0 ECR
Channel 2
Turns Service 2
Encryption ON/OFF
ON
OFF
*.ECMD1 ECR
Mode
Determines whether the
encoder will pass the
transport stream through
the Encryption Block.
Only one encryption
mode is supported at a
time ( BISS1 or BISSE ),
but each channel has
individual control.
OFF
BISS_1
BISS_E_USER_ID_ONE
BISS_E_USER_ID_TWO
*.ECMD# ECR
Clear SW
12-digit hexadecimal
Clear Session Word used
with BISS1
CSW
*.ECMD0 ECR CSW [key]
Encrypt SW
16-digit hexadecimal
Encrypted Session Word
used with BISSE
ESW
*. ECMD0 ECR ESW [key]
User ID 1
14-digit hexadecimal
user id 1 used with
BISSE
AID1
*.ECMD0 ECR AID1 [key]
User ID 2
14-digit hexadecimal
user id 2 used with
BISSE
AID2
*.ECMD0 ECR AID2 [key]
