ADURO 5.1 - Technical Data

33
1. General
1.1 Compliance
Aduro 5.1 complies with the EN13240 European standard as well as the NS3058 Norwegian standard and is
thereby approved for installation and use in Europe. At the same time, the manufacturing process is subject
to external quality control. DoP (Declaration of Performance) can be downloaded at
www.adurofire.com/download.
1.2 Technical data
Aduro 5.1
Data
Nominal power
7.0 kW
Flue outlet, diameter
Ø15 cm top/rear
Measurements (HxWxD)
57.4 x 63.5 x 46 cm
Distance from centre of exhaust branch to rear edge of
stove
19 cm
Weight
77 kg
Material
Sheet iron
Fuel
Wood and wood briquettes
Max wood length
40 cm
Convection stove
Primary, secondary, and tertiary air supply
Air-wash system
Ashpan
Energy efficiency
78.7 %
Energy efficiency index
105.1
Energy efficiency class
A
Chimney draft
12 Pa
Maximum combustion amount per hour (wood)
Approx. 3.4 kg
Heat rating in buildings with
- Optimum insulation
- Average insulation
- Inadequate insulation
175 m
2
115 m
2
70 m
2
1.3 Transportation
When taking your fireplace insert home, please ensure that it travels in an upright position. If you wish to lay
it flat, it is important that you remove all loose parts from the combustion chamber (cast iron grate and loose
fireproof tiles) and remove the ashpan. Please use wood from the packaging for the first use. The plastic
packaging should be discarded.
