2.2 Attachment / hanging of the stove
Aduro 9.4 must be installed on a non-flammable wall. The stove is being delivered with wall fittings which
must be properly fastened to the wall before mounting the stove. You may consult your normal supplier of
building materials about suitable attachment materials such as screws / bolts / anchors for the stove/wall
before the mounting. ONLY USE FIXING MATERIALS WHICH CANNOT MELT. The stove weighs 88 kg. If
you have any doubts about the requirements, please consult your chimney sweep who will inspect the stove.
When the wall fittings are mounted and fastened correctly, the stove can be pushed into place. Thereafter,
the stove must be fastened to the wall fittings with a screw under the bottom. The stove may also be
adjusted at the top of the wall fittings
(see illustration).
2.3 Pipe connection
Aduro 9.4 leaves the factory with the flue outlet mounted on the top. If you require the flue outlet on the back,
“brake” the two cover plates on top of the back of the stove. Exchange the exhaust connector (from the top
outlet) with the cover plate from the rear outlet. Mount the cover plate from the rear outlet to the top outlet.
The top outlet is finished with the plate that lies in the ashpan. A flue pipe with an internal diameter of 150
mm should be used for Aduro stoves.
Please ensure that all local rules and regulations are complied with, including CE marking of the exhaust
connector. Additionally, distance requirements to flammable material for the exhaust connector must be
respected.
2.4 Connection to a brick chimney
