Advanced Navigation Poseidon - 4 Specifications; Mechanical Drawings

Poseidon Reference Manual
Page 5 of 11
Version 2.0
17/12/2016
4 Specifications
4.1 Mechanical Drawings
Illustration 1: Mechanical drawings of Poseidon
4 x M4 5mm
38mm
38mm
23.14mm
67mm
3.8mm
3.0m 30mm
65mm
