Advanced MxPro 5 Mx-5100 User Manual

www.advancedco.com
8
Install the panel, detection loops, sounder circuits, etc. in accordance with the instructions in Section 2
and then program the operation in accordance with the instructions detailed in Section 3.
1.4 EN54 Functions
This Fire Alarm Control Panel is compliant with the requirements of EN54-2 (1997)
and EN54-4 (1997) and EN54-13 (2005).
In addition to the basic requirements, the following optional functions are provided
and these comply with the requirements of EN54.
C.I.E Optional Functions
EN54-2 Clause
Indication
Outputs
Controls
Outputs to Fire Alarm Devices
Outputs to Fire Routing Equipment
Output to Fire Protection Equipment
Investigation Delays to Outputs
Co-incidence Detection
Alarm Counter
Fault Signals from Points
Output to Fault Routing Equipment
Disablement of Points
Test Condition
Standardised I/O
7.8
7.9
7.10
7.11
7.12
Type B & Type C
7.13
8.3
8.9
9.5
10
11
P.S.E Functions
EN54-4 Clause
Operation from a main power supply
Operation from a standby battery
Monitor and Charge the Standby Battery
Recognise and Notify Supply Faults
5.1
5.2
5.3
5.4
System Functions
EN54-13 Clause
Transmission Path Integrity
Networks (non hierarchical)
4.5
4.3
This Fire Alarm Control Panel also supports additional functions that are not covered
by EN54. These are as follows:
Additional Function
Refer to
Paragraphs
Auxiliary Power Supply Output
Auxiliary Relay Outputs
Programmable Cause / Effect on Outputs (Phased Evacuation)
Printer Option
2.5.7
2.5.6
5.4
User Manual

Advanced MxPro 5 Mx-5100 Specifications

General

Brand	Advanced
Model	MxPro 5 Mx-5100
Category	Fire Alarms
Language	English
