5.4.4 Output Group Programming
To achieve the above cause and effect requirements, the three different Output Groups would be programmed
and indicated on the panel as in the following display examples:
Output Group 6 – Sounders on Floor 6:
[Output Group 6] [ 3.9% Mem used]
ZONE CAUSE STYLE=Delay->MODE Wait
22 ANY FIRE 02 30s Pulse 120s
23 ANY FIRE 02 30s Pulse 120s
24 ANY FIRE 02 30s Pulse 120s
[STYLE 02 ]
MODE Wait MODE
On
On
On
Output Group 7 – Sounders on Floor 7:
[Output Group 7] [ 3.9% Mem used]
ZONE CAUSE STYLE=Delay->MODE Wait
22 ANY FIRE 00 - On
23 ANY FIRE 00 - On
24 ANY FIRE 00 - On
[STYLE 00 ]
MODE Wait MODE
Output Group 8 – Sounders on Floor 8:
[Output Group 8] [ 3.9% Mem used]
ZONE CAUSE STYLE=Delay->MODE Wait
22 ANY FIRE 02 30s Pulse 120s
23 ANY FIRE 02 30s Pulse 120s
24 ANY FIRE 02 30s Pulse 120s
[STYLE 02 ]
MODE Wait MODE
On
On
On
To Next Page
