Advanced MxPro4 Installation Sheet & Quick Reference Guide

MX-4100 MX-4010 / MX-4020
340
135
135
23
274
315
365
45
140
140
277
340
EARTH
LIVE
NEUTRAL
230V AC 50Hz 0.4A
POWER SUPPLY
OPTION (4100/L Only):
MXP-007 2-WAY RELAY CARD
See document 680-028
and/or
MXP-014 8-WAY INPUT CARD
See document 680-031
4100 320 x 345 x 88 mm
4100S 320 x 345 x 88 mm
4100/L 340 x 368 x 125 mm
ENCLOSURE: Steel IP30 RAL7035
DIMENSIONS:
ENCLOSURE: Steel IP30 RAL7035
DIMENSIONS: 218 x 300 x 44 mm
113
113
296
213
23
173
INPUT
SCR
B
A
PSE EN54-4,
24V [15V-30V] DC 0.2A
OUTPUT 1
To Next Unit
POWER SUPPLY
PSE
FAULT
SCR
B
A
NETWORK
MX-4010, MX-4020 Standard Network
MX-4010/FT, MX-4020/FT Fault Tolerant Network
OUTPUT
For more information see document
680-029
