Display Items Field Range
Bar Graph
From -999999.0 to +999999.0
To -999999.0 to +999999.0
Trend Graph
Range of X axis (From) -999999.0 to +999999.0
Range of X axis (To) -999999.0 to +999999.0
Range of Y axis (From) -999999.0 to +999999.0
Range of Y axis (To) -999999.0 to +999999.0
Update Rate 0 to 9999
XY Graph
Range of X axis (From) -999999.0 to +999999.0
Range of X axis (To) -999999.0 to +999999.0
Range of Y axis (From) -999999.0 to +999999.0
Range of Y axis (To) -999999.0 to +999999.0
Size of the Trace Buffer 0 to 8192
Group Box Border Width 0 to 32767
Numeric/String Update Rate 0 to 9999
Numeric Control
Privilege Level 0 to 255
Initial Value -999999.0 to +100000000.0
Step Value -999999.0 to +100000000.0
High Limit -999999.0 to +100000000.0
Low Limit -999999.0 to +100000000.0
Knob Control
Privilege Level 0 to 255
Initial Value -5 to 5
Start Tics 2 to 40
End Tics 2 to 40
Tics Rate 2 to 40
Decimal Places 0 to 6
Anameter Tics Number 2 to 40
Historical Trend
Char Span
depends on graph size and
resolution
Number of Tics 2 to 40
(7) Input Range for Display Items
