ICR-2701
2.4 LED S tatus Indication
There are LED indicators on the front panel of the router to provide router status informa-
tion. Moreover, ETH connector, has two additional LEDs providing information about the port
status.
Caption Color State Description
PWR Green
Green
Green
On
Blinking
Fast blinking
Starting of the router
Router is ready
Updating firmware
ETH0
ETH1
Green
Green
On
Off
Selected 100 Mbps bit rate
Selected 10 Mbps bit rate
ETH0
ETH1
Orange
Orange
Orange
On
Blinking
Off
The network cable is connected
Data transmission
The network cable is not connected
Table 6: LED Status Indication
15
