USC-360 Startup Manual 3
2. Before attaching 10.1” display to the rear of USC-360
with 2pcs screws, need Type-C cable to traverse rear
mount bracket of 2nd display.
3. Connect the other end of Type-C cable to Type-C IO
used for DP in USC-360.
10.1”&15.6”2ndDisplayInstallation
1. Make Type-C cable traverse the single hinge stand of
2nd display rstly.
IOHubInstallation
1. Firstly put one side of Hub into the slot of base, then
push the other side of the Hub down as you pull the
other side of the slot outwards with your hand.
2. Make Type-C cable traverse the base, and then con-
nect the cable to I/O.
10.1”2ndDisplayRearMountInstallation
1. Remove VESA cover and cable cover to expose screw
holes.
InstallationProcedures(Cont.)
InstallationProcedures(Cont.)
To Next Page
