Model
Rated
BTU
Output
Electrical
Rating
Compressor
Rated
Amperage
Locked
Rotor
Amperage
Fan
Amperage
Locked
Fan Rotor
Amperage
(High
Speed)
(cfm)
(oz)
Min.wire
size
AC circuit
(User
supplied)
Unit
dimensions
(in)
(lbs)
AC135HP 13500
115VAC
60HZ
1PH
12.4 (C)
10.4 (H)
61 2.5 5.8 500 26.5
12AWG
copper
up to
24'
20 Amp
35.1 x 29.9 x
13.2
92
AC150HP 15000
13.5 (C)
11.5 (H)
66 2.5 5.8 500 29.7 20 Amp
35.1 x 29.9 x
13.2
95
Notes:
1. Consult the National Electric Code for proper sizing for wire lengths over 24 ft.
2. When sizing the generator, the total power usage of your recreational vehicle must be
considered. Keep in mind generators lose power at high altitudes and from lack of
maintenance.
3. CIRCUIT PROTECTION: Time Delay Fuse or HACR Circuit Breakers Required.
INSTALLATION INSTRUCTIONS
1. PRECAUTIONS
A. Read installation and operating instructions carefully before attempting to start your air
conditioner / heat pump installation.
B. The manufacturer will not be liable for any damages or injury incurred due to failure to
follow these instructions.
C. Installation must comply with the National Electrical Code and any State or Local Codes or
regulations.
D. DO NOT add any devices or accessories to this air conditioner / heat pump except those
specifically authorized by manufacturer.
E. This equipment must be serviced by qualified personnel and some states require licensed
personnel.
2. CHOOSING A LOCATION FOR THE AIR CONDITIONER / HEAT PUMP
This product is designed for use as a RV roof top air conditioner / heat pump. The use of this
product in other applications will void the manufactures warranty.
A. NORMAL LOCATIONS:
The heat pump is designed to fit over an existing roof vent opening. When the vent is removed,
it normally creates a 14-1/4" x 14-1/4" ±1/8” opening.
B. OTHER LOCATIONS:
When a roof vent is not available or another location is desired, the following is recommended:
