Assembly Instruction Manual
Switch with Safety-Car device
Code 722A
Description of basic functions
English
Safety device
BUTTON
YELLOW LED
TWO-COLOUR
RED/GREEN LED
3 GREEN LEDS
G 1/4
2/4 3/4 4/4 o B
Use on vehicles with carburettor with electronic reduction gear•
Reprogrammable:•
- Settable as SAFETY-CAR PLUS RESERVOIR FILLING AND EMPTYING (default set-
ting) or SAFETY-CAR PLUS RESERVOIR EMPTYING
Possibility to be used with different sensor types:•
- A.E.B.
- 0÷4700 Ohm
- 0÷90 Ohm
- RESERVE
Adjustable priming time•
Built-in Safety-Car device for enabling the GAS solenoid valves only with the engine •
running, activates automatic GAS delivery blocking within 1 second from the accidental
switching off of the engine.
Installation
Can be installed using the support bracket included in the package•
Canbeinstalledush-mountedinthedashboardusingtheheatcutter•
(to be requested separately)•
NOTE: The switch is supplied without sensors, so in order to get indication of
the fuel level you have to request the relevant sensor (METHANE or LPG) sepa-
rately.
Priming time
Priming time adjustable between 0 and 8 seconds to make starting up the vehicle easier •
by temporarily opening the GAS solenoid valves.
