AEB MP6C - Page 4

tyco
WHITE
GREEN
BLACK
POWER RELE’
LEVEL
SENSOR
GND
GAS CONTROLLER CONNECTOR
G
R
SERIAL INTERFACE SOCKET
YELLOW/GREEN
GREEN
1
9
8
16
OBD CONNECTION
(SEE PAGE DEDICATED)
VIOLET
GRAY
VIOLET/BLACK
GRAY/BLACK
CHANGE OVER SWITCH
PRESSURE REGULATOR
SOLENOID VALVE
OXYGEN
SENSOR 1
OXYGEN
SENSOR 2
ORANGE
BLACK
WATER TEMPERATURE SENSOR
1234
BLUE
BLACK
12
BLUE/WHITE
BLACK
+
-
BATTERY
RED/BLACK
BLACK
FUSE
MAX 15A
GND
FUEL TANK
SOLENOID VALVE
WARNING
RAIL INJ GAS WIRING WITH RED STRIP
AND CUT INJECTORS WIRING WITH RED
STRIP MUST BE COMBINED ON THE
SAME BANK
OPTIONAL
OPTIONAL
+
-
RED STRIP
PETROL CUT-INJECTOR CABLE
WARNING!
THE CONNECTOR OF THE GAS
INJECTOR
E MUST
CORRESPOND TO THE BLUE WIRE
OF THE PETROL
CUT-INJECTOR CABLE.
THE WIRES TO INTERRUPT ARE
INJECTORS NEGATIVE WIRES.
WARNING!
THE CONNECTOR OF THE GAS
INJECTOR
A MUST
CORRESPOND TO THE BLUE WIRE
OF THE PETROL
CUT-INJECTOR CABLE.
THE WIRES TO INTERRUPT ARE
INJECTORS NEGATIVE WIRES.
RED STRIP
GREEN-BLACK
RED-BLACK
BLUE-BLACK
GREEN
BLUE
RED
GREEN-BLACK
RED-BLACK
BLUE-BLACK
GREEN
BLUE
RED
+12 VOLT WITH IGNITION KEY
WHITE-RED
INTAKE
MANIFOLD
PETROL
INJECTORS
3 CYLINDERS GAS
RAIL INJECTORS
GAS INLET
EF
G
121212
PETROL
INJECTORS
INTAKE
MANIFOLD
3 CYLINDERS GAS
RAIL INJECTORS
GAS INLET
ABC
121212
PETROL CUT-INJECTOR CABLE
GAS PRESSURE, TEMPERATURE
AND MAP SENSOR
YELLOW/GREY
STANDARD SENSORS
0÷90 OHM
WHITE
GREEN
GND
0
1/2
4/4
A.E.B. STANDARD
SENSORS TYPE 1050
GND
WHITE
DO NOT LINK GREEN WIRE
A.E.B. STANDARD
SENSORS
GND
200
300100
0
WHITE
GREEN
BROWN
ENGINE RPM
REFERENCE
RPM
1X
4X
7X
