1. Scope
This specification shall be applied to Lithium ion polymer battery- model number
AE8867220PMHRE manufactured by Advanced Electronics Energy Ltd. Hong Kong.
2. System: Rechargeable Lithium-ion Polymer Battery
3. Cell Model : AE8867220P
4. Cell Model Number : AE8867220PMHRE
5. Ratings
5.1. Nominal Capacity [at 0.2C (1940mA)]: 9700mAh (min );
10500mAh (typical )
5.2. Nominal Voltage 3.7V (average voltage at 0.2C discharge)
5.3. Charging Voltage : 4.20 ±0.05V
5.4. Max. Charging Current : 9700mA
5.5. Charging Method: constant current constant voltage
Standard Charge(0.5C): 4850mA (constant current) charge to 4.20V, then 4.2V
(constant voltage) for 3.5hr or 194mA(0.02C) cut off
Quick Charge(1.0C): 9700mA (constant current) charge to 4.20V, then 4.2V
(constant voltage) for 3.0hr or 194mA(0.02C) cut off
5.6. Max. Continuous Discharge Current: 19400mA
5.7. Discharge Cut-off Voltage : 2.75V
5. 8. Cell Dimensions (Refer to the attached drawing)
Thickness : 8.8±0. 3mm
（Measured with weighing 300gf at 25±2℃)
Width : 67.0±0.5mm
（Measured with weighing 300gf at 25±2℃)
Length
: 220.0 ±1mm (not including tab length)
5.9. Cell Weight : 258.0±15.0g
AEenergy Li Polymer Rechargeable Battery
Product Specifications– AE8867220PMHRE
Specification Number: AE8867220PMHRE -FPS-Spec1 Version 1 Page 4/13
