AEG Automatic - Appliances with hot and cold water fill

Water Connection
24
Appliances with hot and cold water fill
Washing machines with hot and cold fill should be connected as shown
below.
WARNING: The incoming hot water temperature must not
exceed 70°C.
If only a cold water supply is available, connect the two hoses to the cold
water outlet by means of a “Y“ connection piece. (A “Y“ piece is available
from your AEG Service Force Centre, part number 645430709).
hot
hot
cold
