Appliance Installation
18
Removing Transit Packaging
• Ensure all transit packaging is removed prior to installation.
• Retain transit packaging for future use.
3
The appliance is supplied with a spanner (H) and plastic caps (E) (2 pcs.)
and (G) (1 pc).
0 Remove the hose holder (A).
0 Remove the 2 screws (B) with the spanner supplied (H).
0 Remove the 4 screws (C).
0 Remove the transit bar (D).
0 Cover the holes left by screws (B) the 2 plastic caps (E).
0 Replace the 4 screws (C), for safe keeping.
0 Remove the screw and compression spring (F) with the spanner (H),
cover the hole with plastic cap (G).
Important: When fitting the plastic caps, press until they snap into the
rear panel securely.
B
C
C
B
D
H
A
E
G
F
