Step 4 Hold the door trim (B) on
the top edge of the door at
the two sides and push in-
wards to release the clip
seal.
Step 5 Pull the door trim to the
front to remove it.
Step 6 Hold the door glass panels
on their top edge one by
one and pull them up out of
the guide.
Step 7 Clean the glass panel with
water and soap. Dry the
glass panel carefully. Do not
clean the glass panels in the
dishwasher.
Step 8 After cleaning, do the
above steps in the opposite
sequence.
Step 9 Install the smaller panel first, then the larger and the door.
Make sure that the glasses are inserted in the correct position otherwise the
surface of the door may overheat.
11.7 How to replace: Lamp
WARNING!
Risk of electric shock.
The lamp can be hot.
Before you replace the lamp:
Step 1 Step 2 Step 3
Turn off the oven. Wait until
the oven is cold.
Disconnect the oven from
the mains.
Put a cloth on the bottom of
the cavity.
www.aeg.com40
