30
10 Grill plate
11 Cover handle
12 Handle notch
13 Sheet
14 Hook
Without image: Reector plate
Scope of delivery
1x Grill base
4x Legs
4x Carriage bolds M5
4x Wingnuts
1x Tray
1x Reector plate
1x Heating element with thermostat
1x Grill plate
1x Plastic mount for hook
1x Cover
1x Cover handle
2x Sheet metal screws Ø 3mm, length 9mm
1x Sheet
1x Hook
1x Screw M4, length 20 mm
Unpacking the device
Unpack the device.
Remove all packaging materials such as
foils, lling material, cable ties and cardboard
packaging.
Check the scope of delivery.
Note:
There might be particles or production remains
on the device. We recommend you wipe the
enclosure with a damp cloth.
Installation
You may assemble the grill with legs (5) using it
as pedestal grill or without legs using it as table
top grill. Please observe gure a.
Pedestal grill
Take the gill plate (10), heating element with
thermostat (7) and the reector plate (without
image) from the grill base (3).
Turn the grill base upside down.
Attach the legs (5) with the open end to the
stand pipes (4) of the grill base.
•
•
•
•
•
•
Note:
There are boreholes in the middle of the
stand pipes.
Use the included screws and nuts to t the tray
(6) here.
Put the device on the stand pipes.
Check all stand pipes are securely attached to
the legs.
Cover (wind deector)
Attach the handle (11) to the cover. Please
mind the notch (12).
Turn the cover over.
Use the two sheet metal screws, Ø 3mm, to
fasten the handle inside the cover (see gure
b).
Put the sheet (13) into the cover as shown in
the gure.
Use the M4 screw, length 20 mm, to attach the
hook (14) and the sheet to the cover.
Do you want to use the assembled cover as wind
deector?
You may hook the cover into the plastic mount
(2).
Grill base
Put the plastic mount (2) into the notch of the
grill base.
Put the reector plate into the grill base.
Pour 1.5 l of cold water into the grill base, as
to cover the plate. You will nd a “MIN”/ “MAX”
marking inside the grill base underneath the
plastic mount.
Caution:
Fill with water until above the reector plate.
The water bath and the plate will prevent
excessive radiated heat near the base of the
device. Therefore always barbecue using
water and the tted reector plate.
Put the heating element with thermostat onto
the grill base.
Note:
The thermostat is equipped with a safety switch
(A). It prevents the operation of the heating ele-
ment outside of the grill base.
Check the correct tting of the thermostat in the
grill base.
•
•
•
1.
2.
3.
4.
5.
1.
2.
3.
►
4.
