3.6 Terminal board
Do not remove blanking
plates.
Make sure that the links are fitted as
shown.
N N N
LL
4. PRODUCT DESCRIPTION
4.1 General overview
1
2
3
3
4
5
5
6
5
4
3
2
1
8
3
2
1
4
7
1
Control panel and hob
2
Air vents for the cooling fan
3
Heating element
4
Lamp
5
Shelf support, removable
6
Fan
7
Cavity embossment
8
Shelf positions
4.2 Hob overview
180 mm
145 mm210 mm
140 mm
145 mm
1
1
121
1
Cooking zone
2
Residual Heat Indicator
