Electrical connection
1)
Voltage (V) 200 - 240
Frequency (Hz) 50 / 60
Wattage (W) 1550-2200
Water supply pressure bar (minimum and maximum) 0.5 - 8
kPa (minimum and maximum) 50 - 800
Water supply Cold water min 5 °C
Capacity Place settings 14
1)
Refer to the rating plate for other values.
14. INSTALLATION
14.1 Fitting under a counter
The plinth of a freestanding appliance is
not adjustable. Do not remove the work-
top if you want to use the appliance as a
freestanding unit.
It is not necessary to remove the work-
top when installing under a standard
kitchen counter. Only remove the work-
top when installing the appliance under a
close fitting sink unit or kitchen counter
(820 mm).
Put the appliance adjacent to a water tap
and a water drain.
Make sure that the dimensions of the
recess agree with the dimensions in the
picture.
Removing the work-top
1. Remove the rear screws (1).
2. Pull the work-top from behind (2).
3. Lift the work-top and move it from
the front slots (3/4).
4. Level the appliance using the
adjustable feet.
5. Install the appliance under the
kitchen counter.
Adjusting the level of the
appliance
A correct adjustment of the level of the
appliance allows the door to close and
seal correctly.
ENGLISH
21
