8.3 To attach the seal.
• Clean the worktop in the area of the
cut out section.
• Bond the seal stripe supplied on the
lower edge of the appliance along the
outer edge of the glass ceramic. Do
not extend it. Let stay the cut ends in
the middle of one side. When, you cut
it to length (add some mm), push the
two ends together.
8.4 Assembly
min.
50mm
min.
50mm
min.
500mm
340
+1
mm
490
+1
mm
R 5mm
55mm
min.
12 mm
min.
20 mm
14
