3. PRODUCT DESCRIPTION
3.1 Cooking surface layout
1 1
1
2
1
2
1
Induction cooking zone
2
Control panel
3.2 Control panel layout
1 2 3
10
11
12
4 5 6
7
8
9
Use the sensor fields to operate the appliance. The displays, indicators and sounds tell
which functions operate.
Sensor
field
Function Comment
1
ON / OFF To activate and deactivate the hob.
2
Lock / The Child Safety De-
vice
To lock / unlock the control panel.
3
Bridge To activate and deactivate the function.
4
- Heat setting and timer dis-
play
To show the heat setting and time in mi-
nutes.
5
- To set the timer function.
ENGLISH 7
