AEG HK955070FB - Product Description; Control panel layout

protection box accessory may not be
available in some countries. Please
contact your local supplier.
You can not use the
protection box if you install
the hob above an oven.
4. PRODUCT DESCRIPTION
4.1 Cooking surface layout
145/210/270
mm
145/210/270
mm
145 mm
180 mm180 mm
170 mm
265 mm
170 mm
265 mm
2 11
1 11
1
Cooking zone
2
Control panel
4.2 Control panel layout
2 31
910
4 6
12 11
875
Use the sensor fields to operate the appliance. The displays, indicators and sounds tell
which functions operate.
Sensor
field
Function Comment
1
ON / OFF To activate and deactivate the hob.
2
Lock / Child Safety Device To lock / unlock the control panel.
3
Pause To activate and deactivate the function.
4
- Heat setting display To show the heat setting.
5
- Timer indicators of cooking
zones
To show for which zone you set the time.
6
- Timer display To show the time in minutes.
www.aeg.com8
